May 2017 Geotechnical Investigation for Farasa fields

Location: Alborz Province

Type: Onshore Geotechnical Investigation

Client: Farasa Company

Field Work: The field work consists of near 80m Geotechnical drilling, sampling and in-situ testing such as SPT, Piezometer, Pressuremeter. Allowable bearing capacity and settlement of different types of foundation in addition with soil characteristics must be determined for engineering purposes.

Laboratory Services: Determination of soil characteristics, resistivity and consolidation test, Chemical test, etc.











May 2017 Geotechnical Investigation for warehouse buildings

Location:Tehran Province

Type: Onshore Geotechnical Investigation

Client: Plasser & Theurer

Field Work:The project consists of drilling 5 exploratory boreholes with 20 to 40 meters depth in continuous coring procedure and core sampling, SPT, Plate load, Pressuremeter test,Down Hole tests.

Laboratory Services: Determination of soil characteristics, resistivity and consolidation test, Chemical test.











April 2017 Provision of remedial services for wellhead services

Location: Persian Gulf

Type: Offshore Pile Design

Client: NAUTIC AWT

Outcomes: previous geotechnical and structural studies reviewed and checked and new grouted pile designed.















January 2017 Seabed Geotechnical Survey and Leg Penetration Analysis for Installation of DC-1 Jack-up at the Location of Azim Gostaresh of Hormoz Ship Yard

Type of Project: Offshore Geotechnical Investigation

Client: AGH , DCI

Location: Bandarabbas

Field Work: According to the scope of work two sampling boreholes and SPT boreholes were drilled each  30 meters deep below mud line. Undisturbed samples with Shelby by continuous coring method were obtained. One CPTu borehole with 10m depth (until refusal) is considered to be drilled.

Laboratory Services: Determination of soil classification, Atterberg limits, particle size distribution, moisture content, bulk density, consolidation test, confined compression test, unconsolidated undrained triaxial, consolidated undrained triaxial, carbonate content, etc.

Seismic Hazard Analysis: Determination of Seismicity Parameters, Risks of Landslides, maximum Ground Acceleration, etc.

 Flood control studies: Calculation of Flood Volume, specified Flood Zoning, Design of Flood Control System, etc.

Outcomes: The purpose of the offshore geotechnical investigation is to acquire detailed  information on the sub seabed soil conditions and geotechnical properties to enable engineering analysis to be performed for determination of soil parameters and Leg penetration analysis for the jack-up set up location.

November 2016 Spudcan Penetration Analysis for PASARGAD-100 Rig Installation at the WPE-1 Platform's EILAM Oil Field

Type of Project: Offshore and Onshore Geotechnical Investigation

Client: OKDC , IOOC

Location: EILAM Oil Field at WPE-1 Location

Field Work: The project consists of 3 boreholes with maximum depth 31.2 meters and allowable bearing capacity and settlement of Spudcan for leg penetration analysis (LPA) in order to PASARGAD-100 Rig installation at the WPE-1 Platform location.

Outcomes: Leg penetration analysis (LPA)





August  2016, Geotechnical  investigation for Behabad Pelletizing Plant

Type of Project: Onshore Geotechnical Investigation

Client: Parsland Mines Industries Developement Company (Pamidco)

Location: Behabad city

Field work: This Project consists of 12 exploratory boreholes to the maximum depth of 3 meters below the natural ground level with 10 to 30 meters depth. The boreholes were drilled by wash boring method and throughout the operation core and disturbed samples were obtained. SPT, Down hole and also Electrical resistivity tests have done.

Laboratory Services: determination of physical and mechanical properties of the soil layers, classification and shear strength tests, Water content, unit weight, Atterberg limits, particle size distribution, particle density, Strength testing, Un-confined compression test (UCT) and unconsolidated undrained (UU) triaxial, Chlorine Content (Soil and Water), Sulphates Content (Soil and Water), , PH (Smoil and Water) and etc.

Outcome: Final report includes Determination of the type and thickness of soil layers, physical and mechanical properties, Study the liquefaction, swell or collapse potential of soil layers. Determination of dynamic properties, allowable soil pressure and estimation of settlement of shallow foundations, modulus of sub grade reaction, lateral soil pressure and soil-concrete friction coefficient, allowable slope of excavations, type of cement to be used in concreting foundations, soil permeability, earthquake coefficients according to 2800 code and technical suggestions and recommendations with respect to construction operations.

August  2016, Geotechnical Investigation in Fateh Kimia Petrochemical Complex

Type of Project: Onshore Geotechnical Investigation

Client: Fateh Kimia Petrochemical Company

Location: Boushehr

Field work: This Project consists of drilling 31 exploratory boreholes with 5 to 45 meters depth in continuous coring procedure and core sampling, SPT, Plate load, Down Hole tests.

Laboratory Services: determination of physical and mechanical properties of the soil layers, classification and shear strength tests, Water content, unit weight, Atterberg limits, particle size distribution, particle density, Strength testing, Un-confined compression test (UCT) and unconsolidated undrained (UU) triaxial, CBR, Chlorine Content (Soil and Water), Sulphates Content (Soil and Water), Soil Carbonate Content, Soil Organic Content, Total dissolved solids (TDS), PH (Smoil and Water)  .

Outcome: Final report includes Geology zone situation and layout, Physical , chemical and dynamic soil properties, sub water, active and  passive coefficients, permeability, bearing capacity, pile and surface foundation settlement, etc

July 2016 Geotechnical Investigation at Kermanshah Bioethanol Production Plant Project

Type of Project: Onshore Geotechnical Investigation

Client: Moshiran

Location: South Western corner of Iran in Kermanshah city, Bistoon industrial town

Field Work: This Project entailed drilling 16 exploratory boreholes with maximum 30 meters depth including SPT, excavating 15 trial pits for plate load test, in-situ geophysical test with Down-hole method in one borehole and in-situ CBR )

Laboratory Services: Determination of Atterberg limits, Grain size (sieve analysis), Specific Gravity, Water Content, Soil Density, Soil Classification, Triaxial Compression (TUU), Triaxial Compression (TCU), Triaxial Compression (TCD), Direct Shear Test (DST), Consolidation (CON), Collapse potential, Uniaxial compression (UCT), Permeability (PER), Compaction(modified) (COM), CBR, Chlorine Content (Soil and Water), Sulphates Content (Soil and Water), Soil Carbonate Content, Soil Organic Content, Total dissolved solids (TDS), PH (Smoil and Water).

Outcomes: Final report includes description of field work and in-situ testing, boreholes descriptions, physical, mechanical and properties of soil, results of in-situ and laboratory experiments, etc.



June 2016 Geotechnical investigation of  Subsea Gas Pipeline from Salman Oil Field to Sirri Island – Persian Gulf

Client: IPAC, IOOC

Location: Salman Field, Lavan Island

Field work: drilling 5 boreholes with 10 meters depth, field tests (SPT, Pocket penetrometer, and Miniature Shear Vane tests), sampling from soil layers

Laboratory Services: determination of Soil classification, Particle size distribution, Atterberg limits,  Specific gravity, Moisture content, Density,  Uniaxial Compressive Strength test, Point Load Test, Triaxial compression test, Direct shear test, Soil & Water sulphate content, Soil & Water chloride content, Carbonate content of soil, PH values of Water & Soil.

Outcome: Final report includes brief description of determination of the type and thickness of soil layers present at the seabed, study of the physical and mechanical properties of various soil layers, assessment of soil liquefaction potential, technical suggestions and recommendations with respect to trenching, determination of the type of cement to be used in concreting, determination of earthquake coefficients according to 2800 codes.



May 2015 Soil improvement under the foundation of Emam Reza residential-bussines complex

Type of Project: Onshore Geotechnical Investigation

Client: : Bana Consulting Engineer

Location: Mashhad

Out come: Final report includes the micro pile designing on base of previous site investigations and in-situ tests



October 2014 Geotechnical Investigation, Seismic Hazard Analysis And Flood Control Study for Combine Cycle Power Plants Project at Zarand Kerman

Type of Project: Onshore Geotechnical Investigation

Client: MAPNA Group(MD3)

Location: Zarand- Kerman

Field Work: Total of 130m Geotechnical drilling, In-situ Testing and sampling such as SPT, Down-hole test, test pits, Plate Load test, Electrical Resistivity test and Lefranc

Laboratory Services: Determination of soil classification, allowable and ultimate Bearing Capacity of sub-soil, type of foundation, ground water level and Dynamic properties of soil.

Seismic Hazard Analysis: Determination of Seismicity Parameters, Risks of Landslides, maximum Ground Acceleration, etc.

 Flood control studies: Calculation of Flood Volume, specified Flood Zoning, Design of Flood Control System, etc.

Outcomes: Final report includes description of field work and in-situ testing, boreholes descriptions, physical, mechanical and dynamic properties of soil, results of in-situ and laboratory experiments, appropriate methods of ground improvement, determination of soil bearing capacity, etc.

September 2014 Geotechnical Investigation and Seismic Hazard Analysis for Kish Gas Power Plant

Type of Project: Onshore Geotechnical Investigation

    Client: MAPNA Special Projects Construction & Development Co.

Location: Aftab Port- Hormozgan

Field Work: Total of 110m Geotechnical drilling, In-situ Testing and sampling such as SPT, Down-hole test, test pits, plate load test, electrical resistivity test and Lefranc.

Laboratory Services: Determination of soil characteristics, resistivity and consolidation test, Chemical test, etc.

Seismic Hazard Analysis: Determination of Seismicity Parameters, Risks of Landslides, maximum Ground Acceleration, etc.

Outcomes: Final report includes description of field work and in-situ testing, boreholes descriptions and sub-layers characteristics, physical, mechanical and dynamic properties of soil, results of in-situ and laboratory experiments, determination of Allowable bearing capacity, etc.



August 2014 naft-sangin Gheshm Refinery

Type of Project: Offshore and Onshore Geotechnical Investigation

Client: Behin Palayesh

Project of Naft-sanginGheshm Refinery (Gheshm Crude Oil  Refinery) is located at Northern territory of Qeshm Island with total area of almost 30 hectare. In this project, several facilities such as tank farm, structure of process plant, Non-industrial buildings and port such as deck and berth for Ingredients intake and petroleum products have been considered. Geotechnical investigation consists of several drilling boreholes totaling 200m offshore, including 4 boreholes each 40m, and 460m near-shore.Testing of samples to define the subsurface soil conditions and in-situ testing such as SPT, Piezometer, CBR test, plate load test, electrical test, and Down-hole seismic test were performed. Borehole layout includes status and position of the layers at different depth, Soil classification and depth of subsoil or bed rock which are sufficient as the bearing subsoil of major foundation structure are verified. In addition allowable and ultimate bearing capacity of subsoil at the bottom of the shallow foundation, Parameters required for design of deep foundations and Dynamic parameters of soil are determined for engineering purposes.



Barge's Main Particulas:

    Name of Barge

 KAMEL 4

    Year of Built

 2000

    Net Tonnage (NRT)

364.41

    Gross Tonnage (GRT)

109.32

    Length Overall

42.65 m

    Breadth

12.19 m

    Mould Depth

3.05 m

March 2014 Geotechnical Investigation and Soil Mechanics study for construction of Iron Ore concentrate plant of Golfa line 3

 Type of Project: Onshore Geotechnical Investigation

 Client: Fakoor Sanat Tehran

 Location: Gol Gohar- Sirjan

 Field Work: Total of 190m Geotechnical drilling, In-situ Testing and sampling such as SPT, Geo-electrical tests and Down-hole test

 Laboratory Services: Determination of soil characteristics, resistivity and consolidation test, Chemical test

 Outcomes: Final report includes description of field work and in-situ testing, Geological maps,  boreholes descriptions and sub-layers characteristics, physical, mechanical and dynamic properties of soil, results of in-situ and laboratory experiments, determination of Allowable bearing capacity, etc.



May 2014 Siraf Sport and Cultural Complex Geotechnical Investigation Project

Type of Project: Onshore Geotechnical Investigation

Client: IRAN ARCH

Location: Taheri port- Siraf/Bushehr      X=633841, Y=3056567

Field Work: Total of meters of 215 Geotechnical drilling and 2 test pits, sampling and in-situ testing such as SPT and Down-hole test

Outcomes: Soil Characteristics and Allowable bearing capacity



   March 2014 Nashtaroud Geotechnical Investigation Project

Type of Project: Onshore Geotechnical Investigation

Client: Cashalot Engineering and Construction Company

Location: Nashtaroud-Mazadandaran      X=504148, Y=4066571

Field Work: Total of 130m Geotechnical drilling

In-situ Testing: sampling, Down-hole test and Piezometers to evaluate changes in groundwater level are verified

Laboratory Services: Determine soil characteristics, resistivity and consolidation test, Chemical test

Outcomes: Final report includes description of field work and in-situ testing, Geological maps,  boreholes and test pits description, results of in-situ and laboratory experiments, dynamic  properties of soil, determine Allowable bearing capacity, and etc.





January 2014 Sepand-1 Gas Field

Type of Project: Offshore Geophysical Investigation

Client:National Iranian Drilling Company (NIDC)

The project consists of 1 km* 1 km Geophysical Survey including Side Scan Sonar, Sub bottom Profiler, Multibeam Echo sounder survey and also Spudcan penetration Analysis (LPA) for “SEPAND-1”Exploration Well South Pars Gas Filed Development –Iran. 3 boreholes with 30 to 33 meters approximate depth below mud line are drilled by HSC.



November 2013 Qeshm Top Island

Type of Project: Onshore Geotechnical Investigation

Client: Qeshm Top Island Company

The field work consists of near 200m Geotechnical drilling, sampling and in-situ testing such as SPT, Pressuremeter. Allowable bearing capacity and settlement of different types of foundation in addition with soil characteristics were determined for engineering purposes.






October 2013 Yazd ShahidGhandi

Type of Project: Onshore Geotechnical Investigation

Client: Rahnemoon Eghtesad Company

The field work consists of near 300m Geotechnical drilling, sampling and in-situ testing such as SPT, Downhole seismic test. Allowable bearing capacity and settlement of different types of foundation in addition with soil characteristics were determined for engineering purposes.





September 2013 Kerman FooladGhadir

Type of Project: Onshore Geotechnical Investigation

Client: Sanat Pars Company

The field work consists of near 325m Geotechnical drilling, sampling and in-situ testing such as SPT, Downhole seismic test. Allowable bearing capacity and settlement of different types of foundation in addition with soil characteristics were determined for engineering purposes.






August 2013 Padideh Kish

Type of Project: Onshore Geotechnical Investigation

Client: AsarBana Pars Company

The field work consists of near 450m Geotechnical drilling, sampling and in-situ testing such as SPT, pressure meter test and insitu density test. Allowable bearing capacity and settlement of different types of foundation in addition with soil characteristics were determined for engineering purposes.






July 2013 Pasargad Bank Central Office

Type of Project: Onshore Geotechnical Investigation

Client: Pasargad Bank

The field work consists of near 210m Geotechnical drilling, sampling and in-situ testing such as SPT, pressure meter test and Downhole seismic test. Allowable bearing capacity and settlement of different types of foundation in addition with soil characteristics were determined for engineering purposes.




  July 2013 Multi store Parking

Type of Project: Onshore Geotechnical Investigation

Client: Ganjineh Atieh Company

The field work consists of near 200m Geotechnical drilling, sampling and in-situ testing such as SPT, pressure meter test and Downhole seismic test. Allowable bearing capacity and settlement of different types of foundation in addition with soil characteristics were determined for engineering purposes.




  June 2013 Sangan Constantre Factory

Type of Project: Onshore Geotechnical Investigation

Client: Pamidco Company

The field work consists of near 750m Geotechnical drilling, sampling and in-situ testing such as SPT, plate load, electrical resistivity test and Downhole seismic test. Allowable bearing capacity and settlement of different types of foundation in addition with soil characteristics were determined for engineering purposes.




  May 2013 Morvarid Residential Building

Type of Project: Onshore Geotechnical Investigation

Client: Omran and Tose Company

The field work consists of near 50m Geotechnical drilling, sampling and in-situ testing such as SPT, plate load test and Downhole seismic test. Allowable bearing capacity and settlement of different types of foundation in addition with soil characteristics were determined for engineering purposes.




  March 2013 Multi Chamber Cement Factory

Type of Project: Onshore Geotechnical Investigation

Client: Tehran Cement Factory

The field work consists of near 100m Geotechnical drilling, sampling and in-situ testing such as SPT, plate load test and Downhole seismic test. Allowable bearing capacity and settlement of different types of foundation in addition with soil characteristics were determined for engineering purposes.




  February 2013 Sina Azadi Complex

Type of Project: Onshore Geotechnical Investigation

Client: Tose Sina Company

The field work consists of retaining wall designation and supervision which is over 30m height including Verification and proof tests and also quality control of construction is under progress.




  January 2013 Rasht Water Storage

Type of Project: Onshore Geotechnical Investigation

Client: Arman Sazeh Gil Company

The field work consists of near 200m Geotechnical drilling, sampling and in-situ testing such as SPT, and Downhole seismic test. Allowable bearing capacity and settlement of different types of foundation in addition with soil characteristics were determined for engineering purposes. Also the designation of retaining structure with nailing method was done as part of Geotechnical Investigation.






November 2012 Shahrkord Twin Tower

Type of Project: Onshore Geotechnical Investigation

Client: Shahrkord Municipality

The field work consists of near 80m Geotechnical drilling, sampling and in-situ testing such as SPT, Pressure meter test. Allowable bearing capacity and settlement of different types of foundation in addition with soil characteristics were determined for engineering purposes. Also the designation of retaining structure with nailing method was done as part of Geotechnical Investigation.






October 2012 Offshore Residential Complex

Type of Project: Onshore Geotechnical Investigation

Client: Rahnamoon Eghtesad Company

The field work consists of near 120m Geotechnical drilling, sampling and in-situ testing such as SPT, Pressure meter and Downhole Seismic test. Allowable bearing capacity and settlement of different types of foundation in addition with soil characteristics were determined for engineering purposes. The dynamic properties of soil layers were evaluated as part of Geotechnical Investigation.






September 2012 Anzali Port Hotel

Type of Project: Onshore Geotechnical Investigation

Client: Nafta Gas Mad Company

The field work consists of near 120m Geotechnical drilling, sampling and in-situ testing such as SPT, Electrical Resistivity and Downhole Seismic test. Allowable bearing capacity and settlement of different types of foundation in addition with soil characteristics were determined for engineering purposes. The dynamic properties of soil layers were evaluated as part of Geotechnical Investigation.






August 2012 Bahregan SPM

Type of Project: Offshore Geotechnical Investigation

Client: Tehran Berkely Consulting Engineers

The field work consists of near 160m Geotechnical drilling, sampling and in-situ testing such as SPT test. Allowable bearing capacity and settlement of different types of foundation in addition with soil characteristics must be determined for engineering purposes. The dynamic properties of soil layers will be evaluated as part of Geotechnical Investigation.






July 2012 Forooz B Gas Field

Type of Project: Offshore Geophysical and Geotechnical Investigation

Client: Mapna Company

The field work consists of 2 km* 2 km Geophysical Survey including Side Scan Sonar, Sub bottom Profiler, Multibeam Echo sounder survey and also 90m Geotechnical drilling including 3 boreholes each 30m, at the water depth of 70 m. Sampling and CPTu test. Allowable bearing capacity and settlement of Spudcan in addition with soil characteristics were determined for engineering purposes.



Barge's Main Particulars:

    Name of Barge  KAMEL 4
    Year of Built  2003
    Net Tonnage (NRT)   272
    Gross Tonnage (GRT)  905
    Length Overall  57.98 m
    Breadth  15.65 m
    Mould Depth  3.75 m


June 2012 Twin Tower Shahrekord

Type of Project: Onshore Geotechnical Investigation

Client: Shahrekord Municipality

The field work consists of near 75m Geotechnical drilling, sampling and in-situ testing such as SPT and Pressuremeter tests. Allowable bearing capacity and settlement of different types of foundation in addition with soil characteristics must be determined for engineering purposes. The dynamic properties of soil layers will be evaluated as part of Geotechnical Investigation.






May 2012 Bandar Anzali Hotel

Type of Project: Onshore Geotechnical Investigation

Client: Naftagaz Mad Company

The field work consists of near 115m Geotechnical drilling, sampling and in-situ testing such as SPT, Electrical Resistivity, Plate Load and downhole seismic tests. Allowable bearing capacity and settlement of different types of foundation in addition with soil characteristics must be determined for engineering purposes. The dynamic properties of soil layers will be evaluated as part of Geotechnical Investigation.






April 2012 West Kish Gas field

Type of Project: Offshore Geophysical and Geotechnical Investigation

Client: NIDC

The field work consists of 1 km* 1 km Geophysical Survey including Side Scan Sonar, Sub bottom Profiler, Multibeam Echo sounder survey and also 90m Geotechnical drilling including 3 boreholes each 30m, at the water depth of 50m, sampling and CPTu test. Allowable bearing capacity and settlement of Spudcan in addition with soil characteristics were determined for engineering purposes.



Barge's Main Particulars:

    Name of Barge  TASMAN ANN
    Year of Built  1977
    Net Tonnage (NRT)   226.00
    Gross Tonnage (GRT)  860.00
    Length Overall  52.67
    Breadth  17.07
    Mould Depth  3.66 m
     Number of Anchors  6





March 2012 South Pars phase 14

Type of Project: Offshore Geophysical and Geotechnical Investigation

Client: NIDC

The field work consists of 1 km* 1 km Geophysical Survey including Side Scan Sonar, Sub bottom Profiler, Multibeam Echo sounder survey. Geotechnical Report was based on the field report which another company did the drilling, sampling and in-situ tests. Allowable bearing capacity and settlement of Spudcan in addition with soil characteristics were determined for engineering purposes.






January 2012 Shemshad Commercial Complex

Type of Project: Onshore Geotechnical Investigation

Client: Ganjineh Atieh Company

The field work consists of near 140m Geotechnical drilling, sampling and in-situ testing such as SPT, Piezometer, Pressuremeter and downhole seismic tests. Allowable bearing capacity and settlement of different types of foundation in addition with soil characteristics must be determined for engineering purposes. The dynamic properties of soil layers will be evaluated as part of Geotechnical Investigation.
